Semen storage, maintains semen at consistent and uniform temperatures using forced air circulation.
The cabinet is equipped with type-approved electronics, which ensures that the cabinet can maintain a constant temperature of around 16-18 degrees, which is the optimal temperature for storing boar semen.
Digital reading of the temperature on the cabinet door. The temperature can be set inside the cabinet.
Specifications 135 liter incl. 2 shelfs and 2 basket.
Dimensions:
HxWxD: 845x545x600 mm
Volume: 135 liter
Weight: 35 kg
Power supply: 230 VAC 50Hz 85W
Power consumption
Depends on the ambient temperature but will be less than 80 Watt.
Ambient temperature : 0-35°C
Programmable temperature range: 15-20°C
Pre-programmed temperature : 17°C
Deviation: 1°C
Refrigerant: R600
Specifications 248 liter incl. 3 shelfs and 3 basket
Dimensions
HxWxD: 1440x545x600 mm
Volume: 240 liter
Weight: 50 kg
Power supply: 230 VAC 50Hz 110W
Ambient temperature: 0-35°C
Programmable temperature range: 5-20°C
Pre-programmed temperature: 7°C
Deviation: 1°C
Refrigerant: R600
MANUAL
Unpacking
Make sure that the Climax Climate Cabinet is intact.
Read Manual.
Installation
Install in a dust free environment. Keep a 1” clearance at the sides/top and 3” at the back of the Climax Climate Cabinet to allow free circulation of air. In order to conserve electricity do not put your Climax Climate Cabinet near a source of heat, such as a cooker or radiator.
If cabinets are delivered on its side, leave it standing upright for minimum 2 hours before plugged in.
After plugging in the power supply check that the fan inside the Climax Climate Cabinet is activated. It is always active for keeping stability in temperature.
Instructions
The pre-programmed temperature is set to 17°C. The display temperature is the air-temperature inside the cabinet. There is a ± 1°C deviation from this setting.
Press the (1) button once (short time). Now the pre-programmed temperature will be displayed and can be changed by pressing “up arrow” or “down arrow”. After 10 seconds the air temperature inside the cabinet will be displayed again.
LED indicators above the display:
(1) active: Heating element is active.
(2) active: Cooling element is active.
Maintenance
The Climax Climate Cabinet can be cleaned with a moist cloth. Other detergents than dishwashing liquid might damage the surface. Dust can be removed with gentle air pressure or a soft brush.
Service and warranty
There is a 12 months warranty on the Climax Climate Cabinet covering in parts or production. Damage caused by incorrect use is not covered by the warranty nor is the manufacturer liable for compensation due to malfunction.
